Horizontal Bottom Labeling Machine

Short Description:

Model EGBL-600 horizontal bottom labeling machine is a semi-automatic horizontal labeling machine design for the production of slim round bottles,tube products,such as lip balm bottles,lip gloss bottles,lipstick bottles,mascara,eyeliner pen and so on.


Product Detail

Product Tags

Horizontal Bottom Labeling Machine

Model EGBL-600 horizontal bottom labeling machine is a semi-automatic horizontal labeling machine design for the production of slim round bottles,tube products,such as lip balm bottles,lip gloss bottles,lipstick bottles,mascara,eyeliner pen and so on.

Horizontal Bottom Labeling Machine Target Product

Mascara bottom labeling

Mascara bottom labeling

Lip gloss bottom labeling

Horizontal Bottom Labeling Machine Features

Automatic sensor check , no products, no labeling

Labeling Accuracy +/-1mm

Automatic roll label for prevent missing label

Labeling head X&Y position can be adjusted

Touch screen operation

Equipped with counting function

Labeling speed,conveying speed and products feeding speed can be set on the touch screen

Label delay length and alarm length can be set on the touch screen

Labeling cylinder time and sucking label time can be set on the touch screen

Language can be customized as user’s language

Product positioning device ensures high labeling accuracy and also higher labeling speed

Horizontal bottom labeling machine Capacity

50-60pcs/min

Horizontal bottom labeling machine Optional

Transparent label sensor

Hot stamping label sensor

Horizontal Bottom Labeling Machine Specification

Model  EGBL-600
Production type Liner type
Capacity  50-60pcs/min
Control type stepper motor
Labeling accuracy +/-1mm
 Label size range  10«width«120mm,length»20mm
 Display  PLC
 No. of operator  1
 Power consumption  1kw
 Dimension  2100*850*1240mm
 Weight  350kgs

Horizontal Bottom Labeling Machine Youtube Video Link

Horizontal Bottom Labeling Machine Details

1 (9)

Bottles feeding hopper

13

Automatic check the label and correct the position

11

Product sensor

1 (6)

Labeling position can be adjusted

1 (4)

Stepper motor control labeling

1 (5)

Winding roller

12

PLC MITSUBISHI
