Single Nozzle Hot Filling Machine

Short Description:

Model EGHF-01 single nozzle hot filling machine is a automatic filling machine designed for the production of godet and jar filling product,such as lipstick,lip balm,eyeliner ,liquid powder,and other hot pour products.


Product Detail

Product Tags

Single Nozzle Hot Filling Machine

Model EGHF-01 single nozzle hot filling machine is a automatic filling machine designed for the production of godet and jar filling product,such as lipstick,lip balm,eyeliner ,liquid powder,and other hot pour products.

Single Nozzle Hot Filling Machine Target Product

Cream

Single Nozzle Hot Filling Machine Features

Designed for filling nozzle raise /lower

1 set of 3 layer jacketed barrel 25L capacity with stirrer

Electronic timer control filling volume

Dosing volume and gear pump speed controlled by digital input ,Accuracy +/-0.5%

Cooling device (optional )

Automatic cooling indexing table under room temperature

Operation with PLC controlled

Single nozzle hot filling machine Capacity

About 35-40godet/min (Out put dependent on filling volume )

Single nozzle hot filling machine Optional

Filling nozzle with filling moving up by servo motor

Single Nozzle Hot Filling Machine Specification

Model  EGHF-01
Output capacity/hr 2400pcs
Filling type Gear pump
No. Of nozzle 1
Vessel volume 25L/set
 Display  PLC
 No. of operator  1
 Power consumption  2.5kw
 Dimension  2.5*0.7*1.7m
 Weight  150kgs
Air input 4-6kgf

Single Nozzle Hot Filling Machine Youtube Video Link

Single Nozzle Hot Filling Machine Details

3
4
6

Our service

warranty time is one year

supply online support videos and manual for technical service

Supply spare parts any time when you need
